Asustor Lockerstor 10 AS6510T NAS Tower Intel Atom® C3538 8 GB DDR4 0 TB ADM Black

Περιγραφή

Processor

CPU configuration (max): 1

PCI Express slots version: 3.0

Processor codename: Denverton

Processor family: Intel Atom®

Processor code: SR3L7

Processor lithography: 14 nm

Processor cache: 8 MB

Stepping: B1

Processor threads: 4

Processor frequency: 2.1 GHz

Processor model: C3538

Processor cache type: Smart Cache

Maximum internal memory supported by processor: 256 GB

Processor manufacturer: Intel

Thermal Design Power (TDP): 15 W

Processor cores: 4

Tjunction: 100 °C

Tcase: 87 °C

Conflict-Free processor: Yes

Processor socket: BGA 1310

Processor package size: 34 x 28 mm

Processor operating modes: 64-bit

Memory

Internal memory type: DDR4

Internal memory: 8 GB

Maximum RAM supported: 64 GB

Memory clock speed: 2133 MHz

Memory slots: 2

Memory form factor: SO-DIMM

Flash memory: 4096 MB

Design

Built-in display: Yes

Product colour: Black

Cooling type: Active

Display type: LCD

Number of fans: 2 fan(s)

Fan diameter: 12 cm

Chassis type: Tower

Power

AC input voltage: 100 - 240 V

Power consumption (typical): 76.8 W

Number of power supply units: 1

Power supply unit (PSU) capacity: 250 W

Power consumption (HDD standby): 41.1 W

Power supply location: Built-in

Redundant power supply (RPS) support: No

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Operating relative humidity (H-H): 5 - 95%

Weight & dimensions

Weight: 6.4 kg

Depth: 230 mm

Height: 215.5 mm

Width: 293 mm

Network

Wake-on-LAN ready: Yes

Ethernet LAN data rates: 1000 Mbit/s, 2500 Mbit/s, 10000 Mbit/s, 100

Ethernet LAN data rate supported (max): 10000 Mbit/s

Link aggregation: Yes

iSCSI support: Yes

Load balancing system: Yes

Dynamic DNS (DDNS): Yes

WLAN adapter supported: Yes

Ethernet LAN: Yes

DHCP server: Yes

Jumbo frames support: Yes

Performance

Reset button: Yes

Security algorithms: SSH, HTTPS, SSL/TLS, 256-bit AES

Web-based management: Yes

Share folder access right management: Yes

Multilingual support: Yes

Type: NAS

Backup features: Cloud, iSCSI LUN

Disk scan: Yes

Universal Plug and Play (UPnP): Yes

Snapshot: Yes

Share folder: Windows ACL

Number of users: 4096 user(s)

Device class: Home & Home Office

S.M.A.R.T. support: Yes

Access Control List (ACL): Yes

Built-in iTunes server: Yes

Browser supported: Internet Explore 11+, FireFox, Chrome, Safari, Microsoft Edge

Built-in UPnP AV media server: Yes

Noise level (idle): 22 dB

System log: Yes

Backup function: Yes

Packaging content

Number of screws: 66

Cables included: AC, LAN (RJ-45)

Processor special features

Intel® Turbo Boost Technology: No

Intel Secure Boot: Yes

Embedded options available: Yes

Intel Virtualization Technology for Directed I/O (VT-d): Yes

Intel® Hyper Threading Technology (Intel® HT Technology): No

Intel Virtualization Technology (VT-x): Yes

Intel Secure Key Technology version: 1.00

Intel VT-x with Extended Page Tables (EPT): Yes

Intel® Secure Key: Yes

Intel QuickAssist Technology: Yes

Execute Disable Bit: Yes

Maximum number of PCI Express lanes: 12

Intel Secure Boot Technology version: 1.00

Memory types supported by processor: DDR4-SDRAM

Intel® AES New Instructions (Intel® AES-NI): Yes

Intel® OS Guard: Yes

Software

Mac operating systems supported: Mac OS X 10.9 Mavericks, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 12.0 Monterey, Mac OS X 11.0 Big Sur

Windows operating systems supported: Windows Vista, Windows 7, Windows XP, Windows 8, Windows 10

Other operating systems supported: Linux

Server operating systems supported: Windows Server 2012, Windows Server 2008, Windows Server 2003

Linux operating systems supported: Yes

Operating system version: 3.4

Operating system installed: ADM

Storage

RAID levels: 10, 0, 5, JBOD, 6, 1

RAID support: Yes

Supported storage drive types: HDD & SSD

Supported storage drive interfaces: Serial ATA III

Supported file systems: HFS+, ext4, ext3, NTFS, FAT32, BTRFS, exFAT

Total installed storage capacity: 0 TB

Online RAID migration: Yes

Storage drive capacity: 0 GB

Number of storage drives supported: 10

Bad block scan: Yes

Storage drive sizes supported: 2.5, 3.5", M.2

Online RAID expansion: Yes

Number of M.2 (M & B) slots: 2

Storage drives installed: No

Installed storage drive type: No

Ports & interfaces

Ethernet LAN (RJ-45) ports: 4

USB port: Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

Other features

Processor ARK ID: 97929

Logistics data

Harmonized System (HS) code: 84714100
