Platforma Gigabyte Rack (1U) AMD R133-C10-000-AAA2

Περιγραφή

Processor

Motherboard chipset: AMD B650E

Number of processors supported: 1

Compatible processor series: AMD Ryzen 7000 Series, AMD EPYC 4005, AMD EPYC 4004, AMD Ryzen 9000 Series

Processor socket: Socket AM5

Processor manufacturer: AMD

Graphics

On-board graphics card model: Aspeed AST2600

Features

Trusted Platform Module (TPM): Yes

Backplanes support: Yes

Memory

Supported RDIMM clock speeds: 5600, 3600 MHz, 5200 MHz

Supported memory types: DDR5-SDRAM

Number of DIMM slots: 4

Memory channels: Dual-channel

Design

Number of fans: 3 fan(s)

Chassis type: Rack (1U)

Power

AC input voltage: 100 - 240 V

Power supply: 550 W

Number of main power supplies: 2

80 PLUS certification: 80 PLUS Platinum

Operational conditions

Storage temperature (T-T): -40 - 60 °C

Operating relative humidity (H-H): 8 - 80%

Operating temperature (T-T): 10 - 30 °C

Storage relative humidity (H-H): 20 - 95%

Weight & dimensions

Weight: 18.1 kg

Depth: 710 mm

Width: 438 mm

Height: 43.5 mm

Network

Ethernet LAN data rates: 10, 100, 1000 Mbit/s

LAN controller: Broadcom BCM5720

Ethernet LAN: Yes

Ethernet interface type: Gigabit Ethernet

Packaging data

Package weight: 20.1 kg

Package depth: 594 mm

Package height: 250 mm

Package width: 982 mm

Expansion slots

PCI Express x16 slots: 1

Storage

Number of 2.5"/3.5" bays : 4

Storage drive sizes supported: 2.5, 3.5"

Ports & interfaces

Reset button: Yes

Ethernet LAN (RJ-45) ports: 2

Mini DisplayPorts quantity: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
