Płyta ASUS PRO WS W880-ACE SE 90MB1KV0-M0EAY0

Περιγραφή

Processor

Compatible processor series: Intel Core Ultra (Series 2)

Processor socket: LGA 1851 (Socket V1)

Processor manufacturer: Intel

Supported processor sockets: Intel LGA1851

Graphics

Maximum resolution: 3840 x 2160 pixels

Parallel processing technology support: Not supported

Features

Motherboard chipset family: Intel

Product colour: Grey

Audio output channels: 7.1 channels

Power source type: ATX

Motherboard form factor: ATX

Audio chip: Realtek ALC1220P

Windows operating systems supported: Windows 10 x64, Windows 11

Cooling type: Passive

Component for: Workstation

Memory

Unbuffered memory: Yes

Maximum internal memory: 256 GB

ECC сompatibility: Non-ECC

Memory channels: Dual-channel

Maximum internal memory per slot: 64 GB

Supported memory types: DDR5-SDRAM

Number of memory slots: 4

Memory slots type: DIMM

Supported memory clock speed (max): 9066 MHz

Weight & dimensions

Depth: 244 mm

Width: 305 mm

Network

Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet

Ethernet LAN: Yes

Wi-Fi: No

Internal I/O

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1

Number of SATA III connectors: 4

Thunderbolt headers: 1

USB 2.0 connectors: 2

Front panel audio connector: Yes

Number of water pump connectors: 1

Number of temperature sensor headers: 1

Number of COM connectors: 1

EPS power connector (8-pin): Yes

USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1

Number of chassis fan connectors: 5

Number of EPS power connectors (8-pin): 2

12V power connector: Yes

Number of CPU fan connectors: 1

Chassis intrusion connector: Yes

CPU fan connector: Yes

ATX Power connector (24-pin): Yes

Integrated SAS ports: 1

Front panel connector: Yes

BIOS

BIOS memory size: 256 Mbit

Clear CMOS button: Yes

BIOS type: UEFI AMI

Packaging content

Cables included: SATA

Storage controllers

RAID support: Yes

Supported storage drive types: HDD & SSD

Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III

RAID levels: 5, 10, 0, 1

Number of storage drives supported: 8

Number of HDDs supported: 4

Rear panel I/O ports

Ethernet LAN (RJ-45) ports: 3

DisplayPort version: 2.1

Headphone outputs: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6

VGA (D-Sub) ports quantity: 1

Line-in: Yes

HDMI version: 2.1

Thunderbolt ports quantity: 1

HDMI ports quantity: 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

Expansion slots

1st M.2 highest PCI Express generation: 5.0

4th M.2 largest key size: 2280

3rd M.2 largest key size: 2280

4th M.2 highest PCI Express generation: 4.0

Number of M.2 (M) slots: 4

1st M.2 largest key size: 2280

PCI Express x16 (Gen 4.x) slots: 1

2nd M.2 highest PCI Express generation: 4.0

2nd M.2 largest key size: 2280

3rd M.2 highest PCI Express generation: 4.0

PCI Express x16 (Gen 5.x) slots: 2
