Switch TP-LINK ES220GMP

Περιγραφή

Design

Stackable: No

Number of fans: 2 fan(s)

Rack mounting: Yes

Product colour: Black

LED indicators: Yes

Power

Surge protection voltage: 6 kV

Power supply included: Yes

Surge protection: Yes

Power source: AC

AC input frequency: 50/60 Hz

Power consumption (max): 289.7 W

AC input voltage: 100 - 240 V

Security

Queue scheduling algorithms: Weighted Round Robin (WRR)

IGMP snooping: Yes

Loop protection: Yes

DHCP features: DHCP client

Operational conditions

Heat dissipation: 984.88 BTU/h

Operating temperature (T-T): -5 - 50 °C

Operating relative humidity (H-H): 10 - 90%

Storage temperature (T-T): -40 - 70 °C

Storage relative humidity (H-H): 5 - 90%

Management features

Unified static configuration: Yes

Cloud-managed: Yes

Switch layer: L2

Switch type: Managed

Web-based management: Yes

Quality of Service (QoS) support: Yes

Weight & dimensions

Width: 440 mm

Height: 44 mm

Depth: 180 mm

Network

Zero Touch Provisioning (ZTP): Yes

Link aggregation: Yes

Virtual LAN features: Tagged VLAN, MTU VLAN, Port-based VLAN

Auto-negotiation: Yes

Port mirroring: Yes

Number of VLANs: 32

10G support: No

Fast leave: Yes

Flow control support: Yes

VLAN support: Yes

Networking standards: IEEE 802.3i, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3z, IEEE 802.1ab, IEEE 802.3u

Auto MDI/MDI-X: Yes

Performance

Mean time between failures (MTBF): 310550.7 h

Firmware upgradeable: Yes

Flash memory: 64 MB

Noise level: 41.5 dB

Packaging data

Package type: Box

Packaging content

Rack mount kit: Yes

User guide: Yes

Cables included: AC

Certificates

Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)

Ports & interfaces

Gigabit Ethernet (copper) ports quantity: 18

Power connector: AC-in jack

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Basic switching RJ-45 Ethernet ports quantity: 18

SFP module slots quantity: 2

Data transmission

Jumbo frames: 15000

Forwarding rate: 29.76 Mpps

Switching capacity: 40 Gbit/s

Store-and-forward: Yes

MAC address table: 8000 entries

Packet buffer memory: 4 MB

Jumbo frames support: Yes

Power over Ethernet (PoE)

Power over Ethernet plus (PoE+) ports quantity: 16

Power over Ethernet (PoE) type supported: PoE+

Total Power over Ethernet (PoE) budget: 250 W

Power over Ethernet (PoE) power per port: 30 W

Power over Ethernet (PoE): Yes
