Intel Core i5-14600K processor 24 MB Smart Cache Box

Περιγραφή

Technical details

OpenCL version: 3.0

Status: Launched

Launch date: Q4'23

Processor

Processor socket: LGA 1700

Processor cache type: Smart Cache

Memory bandwidth supported by processor (max): 89.6 GB/s

Processor operating modes: 64-bit

Performance cores: 6

Performance-core boost frequency: 5.3 GHz

Processor cores: 14

Processor ARK ID: 236799

Processor threads: 20

Processor model: i5-14600K

Box: Yes

Processor codename: Raptor Lake

Processor cache: 24 MB

Processor base power: 125 W

Processor family: Intel® Core™ i5

Stepping: B0

Processor manufacturer: Intel

Performance-core base frequency: 3.5 GHz

Cooler included: No

Efficient cores: 8

Maximum number of DMI lanes: 8

Processor generation: Intel® Core™ i5 (14th gen)

Maximum turbo power: 181 W

Graphics

On-board graphics card model: Intel UHD Graphics 770

Number of execution units: 32

Discrete graphics card: No

On-board graphics card OpenGL version: 4.5

On-board graphics card outputs supported: DisplayPort 1.4a, HDMI 2.1, Embedded DisplayPort (eDP) 1.4b

On-board graphics card base frequency: 300 MHz

On-board graphics card: Yes

On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz

On-board graphics card dynamic frequency (max): 1550 MHz

Number of displays supported (on-board graphics): 4

On-board graphics card ID: 0xA780

On-board graphics card DirectX version: 12.0

Discrete graphics card model: Not available

On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels

On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels

On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz

On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels

Multi-Format Codec Engines: 2

Features

PCI Express configurations: 1x16+1x4, 2x8+1x4

Thermal solution specification: PCG 2020A

Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2

Embedded options available: No

Maximum number of PCI Express lanes: 20

Scalability: 1S

PCI Express slots version: 5.0, 4.0

Export Control Classification Number (ECCN): 5A992C

Execute Disable Bit: Yes

Market segment: Desktop

CPU configuration (max): 1

Thermal Monitoring Technologies: Yes

Commodity Classification Automated Tracking System (CCATS): 740.17B1

Idle States: Yes

Use conditions: PC/Client/Tablet, Workstation

Direct Media Interface (DMI) Revision: 4.0

Memory

Memory channels: Dual-channel

Memory bandwidth (max): 89.6 GB/s

Maximum internal memory supported by processor: 192 GB

Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM

Non-ECC: Yes

ECC: Yes

Operational conditions

Tjunction: 100 °C

Weight & dimensions

Processor package size: 45 x 37.5 mm

Processor special features

Intel® Speed Shift Technology: Yes

Intel® Clear Video HD Technology (Intel® CVT HD): Yes

Intel® AES New Instructions (Intel® AES-NI): Yes

Enhanced Intel SpeedStep Technology: Yes

Intel® OS Guard: Yes

Intel® Turbo Boost Technology: 2.0

Intel Virtualization Technology for Directed I/O (VT-d): Yes

Intel Virtualization Technology (VT-x): Yes

Intel® Hyper Threading Technology (Intel® HT Technology): Yes

Intel® Volume Management Device (VMD): Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes

Intel 64: Yes

Mode-based Execute Control (MBE): Yes

Intel® Thread Director: Yes

Intel® Secure Key: Yes

Intel® Boot Guard: Yes

Intel® Quick Sync Video Technology: Yes

Intel® Control-flow Enforcement Technology (CET): Yes

Intel VT-x with Extended Page Tables (EPT): Yes

Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes

Intel® Standard Manageability (ISM): Yes

Other features

Maximum internal memory: 192 GB

Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1

L2 cache: 20480 KB

Logistics data

Harmonized System (HS) code: 8542310001

Safety warning

Warnings: Do not dispose of the processors in the normal rubbish bin - they require special disposal due to their potential environmental impact., Ensure that the CPU is properly mounted in the CPU socket to avoid damage.
