ASRock Z890 Pro-A Intel Z890 LGA 1851 (Socket V1) ATX motherboard

Περιγραφή

Technical details

Compliance certificates: Federal Communications Commission (FCC), CE

Processor

Supported processor sockets: LGA 1851

Processor manufacturer: Intel

Compatible processor series: Intel Core Ultra (Series 2)

Processor socket: LGA 1851 (Socket V1)

Features

Windows operating systems supported: Windows 11 x64

Motherboard form factor: ATX

Audio output channels: 7.1 channels

Motherboard chipset: Intel Z890

Audio chip: Realtek ALC897

Motherboard chipset family: Intel

Memory

Number of memory slots: 4

Supported memory clock speed (max): 9066 MHz

Memory slots type: DIMM

Memory channels: Dual-channel

Supported memory types: DDR5-SDRAM

ECC сompatibility: Non-ECC

Maximum internal memory: 256 GB

Unbuffered memory: Yes

Weight & dimensions

Depth: 244 mm

Width: 305 mm

Network

Ethernet LAN: Yes

Ethernet interface type: 2.5 Gigabit Ethernet

Wi-Fi: No

LAN controller: Dragon RTL8125BG

Internal I/O

RGB LED pin header: Yes

Audio connector: Yes

TPM connector: Yes

Number of CPU fan connectors: 2

12V power connector: Yes

USB 3.2 Gen 2x2 connectors: 1

Front panel audio connector: Yes

Number of chassis fan connectors: 5

ATX Power connector (24-pin): Yes

USB 2.0 connectors: 2

Number of SATA III connectors: 4

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2

CPU fan connector: Yes

BIOS

BIOS type: UEFI AMI

Packaging content

Cables included: SATA

Screws included: Yes

Storage controllers

Number of HDDs supported: 4

Number of storage drives supported: 8

RAID levels: 1, 10, 0, 5

Supported storage drive interfaces: M.2, SATA III

RAID support: Yes

Supported storage drive types: HDD & SSD

Rear panel I/O ports

Thunderbolt ports quantity: 1

USB 3.2 Gen 2x2 Type-C ports quantity: 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1

Microphone in: Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

Headphone outputs: 1

HDMI ports quantity: 1

Line-in: Yes

Ethernet LAN (RJ-45) ports: 1

DisplayPort version: 1.4

DisplayPorts quantity: 1

USB 2.0 ports quantity: 4

Expansion slots

PCI Express x4 (Gen 4.x) slots: 2

PCI Express x1 (Gen 4.x) slots: 1

PCI Express x16 (Gen 5.x) slots: 1
