be quiet! BN338 power supply unit 1000 W 20+4 pin ATX ATX Black

Περιγραφή

Technical details

Sustainability certificates: ENERGY STAR, ErP, Triman

Sustainability compliance: Yes

Design

Fan diameter: 13.5 cm

Product colour: Black

Fan speed: 0 - 2100 RPM

On/off switch: Yes

Cooling type: Active

Number of fans: 1 fan(s)

Power

Combined power (+12V): 999.6 W

AC input frequency: 50/60 Hz

Input current: 13/6.5 A

Power protection features: Over power, Over voltage, Under voltage, Over current, Overheating

Hold time: 25.3 ms

Max output current (+5V): 25 A

AC input voltage: 100 - 240 V

Power factor: 0.99

Combined power (+5V): 150 W

Efficiency: 91.8%

Max output current (+5Vsb): 3 A

Total power: 1000 W

Max output current (+12V): 83.3 A

Peak power: 1070 W

Max output current (-12V): 0.5 A

Combined power (+3.3V): 150 W

Max output current (+3.3V): 25 A

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Weight & dimensions

Height: 86 mm

Width: 150 mm

Weight: 1.85 kg

Depth: 160 mm

Performance

Supported motherboard form factors: ATX, micro ATX, Mini-ATX

Purpose: PC

80 PLUS certification: 80 PLUS Platinum

Mean time between failures (MTBF): 100000 h

EPS version: 2.92

Bearing technology: FDB

Power supply unit (PSU) form factor: ATX

ATX version: 3.1

Noise level: 28.9 dB

Packaging data

Package weight: 3.56 kg

Package depth: 328 mm

Package width: 248 mm

Package height: 102 mm

Package type: Box

Packaging content

Cable tie(s) included: Yes

Cables included: CPU, SATA

Certificates

Compliance certificates: RoHS, CE, WEEE, Federal Communications Commission (FCC), UKCA

Ports & interfaces

PCI Express power connectors (6+2 pin): 4

Motherboard power cable length: 60 cm

SATA power cable length: 1000 mm, 550 mm, 700 mm, 850 mm

CPU power cable length: 70 cm

Cabling type: Fully-Modular

EPS power connector (8-pin): Yes

EPS power connector (4+4 pin): Yes

Number of SATA power connectors: 9

Number of PATA power connectors: 2

Peripheral (Molex) power cable length: 850 mm, 1000

Motherboard power connector: 20+4 pin ATX

PCI Express power connectors (16-pin): 1

PCI Express power cable length: 60 cm

Logistics data

Shipping (inner) case length: 65.1 cm

Warranty period: 10 year(s)

Products per shipping (inner) case: 6 pc(s)

Shipping (inner) case width: 28.2 cm

Shipping (inner) case height: 34.6 cm

Shipping (inner) case net weight: 22.9 kg

Safety warning

Warnings: Do not open the case - risk of electric shock., Avoid contact of the product with water or other liquids., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
