Cooler Master MWE Bronze 650 V3 230V power supply unit 650 W 24-pin ATX ATX Black

Περιγραφή

Technical details

Compliance certificates: RoHS, CE, China Compulsory Certification (CCC), UKCA, RCM, BIS, EAC, Federal Communications Commission (FCC)

Design

Product colour: Black

Number of fans: 1 fan(s)

Fan diameter: 12 cm

Cooling type: Active

Power

Combined power (+12V): 648 W

Efficiency: 88%

Max output current (+5Vsb): 3 A

Power protection features: Over power, Overheating, Short circuit, Over voltage, Under voltage

AC input frequency: 50/60 Hz

Combined power (+3.3V): 120 W

AC input voltage: 200 - 240 V

Combined power (+5Vsb): 15 W

Total power: 650 W

Power Good signal delay range: 100 - 150 ms

Hold time: 16 ms

Power Factor Correction (PFC) type: Active

Input current: 5 A

Max output current (+5V): 19 A

Max output current (+12V): 54 A

Combined power (-12V): 3.6 W

Combined power (+5V): 120 W

Max output current (+3.3V): 19 A

Max output current (-12V): 0.3 A

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Weight & dimensions

Width: 150 mm

Height: 86 mm

Depth: 140 mm

Weight: 1.65 kg

Performance

80 PLUS certification: 80 PLUS Bronze

Mean time between failures (MTBF): 100000 h

Bearing technology: HDB

Power supply unit (PSU) form factor: ATX

Purpose: PC/Server

ATX version: 3.1

Packaging data

Package weight: 2.05 kg

Package height: 110 mm

Package depth: 245 mm

Package width: 190 mm

Ports & interfaces

EPS power connector (8-pin): Yes

SATA power cable length: 700, 550, 400 mm

Peripheral (Molex) power connectors (4-pin): 3

PCI Express power connectors (6+2 pin): 4

Number of SATA power connectors: 6

Motherboard power cable length: 50 cm

Peripheral (Molex) power cable length: 400 mm, 550 mm, 700 mm

PCI Express power cable length: 62 cm

Cabling type: Non-Modular

EPS power connector (4+4 pin): Yes

Motherboard power connector: 24-pin ATX

Other features

EPS cable length: 67 cm
