ASUS P13R-E Intel C266 LGA 1700 ATX

Περιγραφή

Processor

Supported processor sockets: LGA 1700

Processor manufacturer: Intel

Compatible processor series: Intel Xeon 6300, AMD Turion X2 Ultra Dual-Core, Intel® Pentium®, Intel Xeon E

Processor socket: LGA 1700

Graphics

Parallel processing technology support: Not supported

Features

Component for: Server

Cooling type: Passive

Power source type: ATX

Motherboard chipset: Intel C266

Product colour: Black

PC health monitoring: Fan, CPU, Temperature

Motherboard form factor: ATX

Motherboard chipset family: Intel

Memory

Memory slots type: DIMM

Number of memory slots: 4

Memory channels: Dual-channel

Supported memory types: DDR5-SDRAM

Supported memory clock speed (max): 4400 MHz

ECC сompatibility: ECC

Maximum internal memory per slot: 32 GB

Supported memory clock speeds: 4000, 4400, 3600

Maximum internal memory: 128 GB

Operational conditions

Operating temperature (T-T): 10 - 50 °C

Storage temperature (T-T): -40 - 70 °C

Storage relative humidity (H-H): 20 - 90%

Weight & dimensions

Depth: 244 mm

Width: 305 mm

Height: 68 mm

Network

Ethernet LAN: Yes

Wi-Fi: No

Ethernet interface type: Gigabit Ethernet

Internal I/O

USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1

Number of chassis fan connectors: 6

EPS power connector (8-pin): Yes

TPM connector: Yes

Front panel connector: Yes

ATX Power connector (24-pin): Yes

Chassis intrusion connector: Yes

Number of COM connectors: 1

12V power connector: Yes

Number of EPS power connectors (8-pin): 1

USB 2.0 connectors: 1

Number of SATA III connectors: 8

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1

Packaging data

Package height: 78 mm

Package weight: 1.5 kg

Package width: 341 mm

Package depth: 281 mm

Storage controllers

Number of storage drives supported: 10

Number of HDDs supported: 8

Supported storage drive types: HDD & SSD

Supported storage drive interfaces: PCI Express 4.0, SATA III

Rear panel I/O ports

Ethernet LAN (RJ-45) ports: 2

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4

VGA (D-Sub) ports quantity: 1

USB 2.0 ports quantity: 2

Expansion slots

PCI Express x4 (Gen 4.x) slots: 2

PCI Express x16 (Gen 5.x) slots: 1

Number of M.2 (M) slots: 2

2nd M.2 highest PCI Express generation: 4.0

PCI Express x8 (Gen 5.x) slots: 1

1st M.2 highest PCI Express generation: 4.0

2nd M.2 largest key size: 22110

1st M.2 largest key size: 22110

Other features

Weight: 800 g

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book.

Σχετικά Προϊόντα

ASUS 90SB0A90-M0UAY0 motherboard LGA 1200 (Socket H5) ATX

ProcessorProcessor socket: LGA 1200 (Socket H5)Compatible processor series: Intel® Pentium®, Intel Xeon EProcessor manufacturer: IntelGraphicsGraphics..

405,34€

Χωρίς ΦΠΑ:326,88€

ASUS P12R-M Intel C252 LGA 1200 (Socket H5) micro ATX

ProcessorCompatible processor series: Intel® Pentium®, Intel Xeon EProcessor manufacturer: IntelProcessor socket: LGA 1200 (Socket H5)GraphicsOn-board..

353,57€

Χωρίς ΦΠΑ:285,14€

ASUS P13R-M Intel C262 LGA 1700 micro ATX

ProcessorProcessor manufacturer: IntelCompatible processor series: Intel® Pentium®, Intel Xeon EProcessor socket: LGA 1700GraphicsGraphics card family..

503,65€

Χωρίς ΦΠΑ:406,17€

ASUS P13R-M Intel C262 LGA 1700 micro ATX

ProcessorProcessor manufacturer: IntelProcessor socket: LGA 1700Compatible processor series: Intel Xeon E, Intel® Pentium®GraphicsGraphics card family..

435,18€

Χωρίς ΦΠΑ:350,95€

Płyta ASUS PRO WS W880-ACE SE 90MB1KV0-M0EAY0

ProcessorSupported processor sockets: Intel LGA1851Compatible processor series: Intel Core Ultra (Series 2)Processor manufacturer: IntelProcessor sock..

638,38€

Χωρίς ΦΠΑ:514,82€

Płyta główna Asus P13R-I 1x LGA1700 Intel Xeon E-24XX C262 (2xDIMM, 6x SATA, 1xM.2, 2x1GbE, ASMB11-iKVM, miniITX)
