Intel Core i5-10400 processor 2.9 GHz 12 MB Smart Cache Box

Περιγραφή

Technical details

Supported memory types: DDR4-SDRAM

Status: Launched

Target market: Gaming

Launch date: Q2'20

Processor ID: 0x9BC8 / 0x9BC5

Bus speed: 8 GT/s

Product type: Processor

Maximum graphics card memory: 64 GB

Maximum memory: 128 GB

Maximum resolution & refresh rate (DisplayPort): 4096 x 2304@60Hz

Processor

Box: Yes

Memory bandwidth supported by processor (max): 41.6 GB/s

Processor base frequency: 2.9 GHz

Cooler included: Yes

Processor ARK ID: 199271

Generation: 10th Generation

Processor generation: 10th gen Intel® Core™ i5

Processor socket: LGA 1200 (Socket H5)

System bus rate: 8 GT/s

Processor lithography: 14 nm

Thermal Design Power (TDP): 65 W

Processor manufacturer: Intel

Processor operating modes: 64-bit

Processor family: Intel® Core™ i5

Processor cache: 12 MB

Processor codename: Comet Lake

Processor boost frequency: 4.3 GHz

Processor cores: 6

Processor model: i5-10400

Processor threads: 12

Component for: PC

Processor cache type: Smart Cache

Graphics

On-board graphics card dynamic frequency (max): 1100 MHz

Maximum on-board graphics card memory: 64 GB

Discrete graphics card: No

Number of displays supported (on-board graphics): 3

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz

On-board graphics card base frequency: 350 MHz

On-board graphics card refresh rate at maximum resolution (HDMI): 30 Hz

On-board graphics card 4K support: Yes

On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz

On-board graphics card ID: 0x9BC8/0x9BC5

On-board graphics card maximum resolution (DisplayPort): 4096 x 2304 pixels

On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels

On-board graphics card OpenGL version: 4.5

On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 4096 x 2304 pixels

Discrete graphics card model: Not available

On-board graphics card DirectX version: 12.0

On-board graphics card: Yes

On-board graphics card model: Intel® UHD Graphics 630

Features

Thermal solution specification: PCG 2015C

Supported instruction sets: SSE4.1, AVX 2.0, SSE4.2

Execute Disable Bit: Yes

Scalability: 1S

Idle States: Yes

Export Control Classification Number (ECCN): 5A992C

Market segment: Desktop

PCI Express CEM revision: 3.0

Commodity Classification Automated Tracking System (CCATS): G077159

Embedded options available: No

PCI Express configurations: 1x8+2x4, 1x16, 2x8

Thermal Monitoring Technologies: Yes

CPU configuration (max): 1

Maximum number of PCI Express lanes: 16

PCI Express slots version: 3.0

Memory

Maximum internal memory supported by processor: 128 GB

Memory types supported by processor: DDR4-SDRAM

Memory clock speeds supported by processor: 2666 MHz

Memory channels: Dual-channel

ECC: No

Operational conditions

Tjunction: 100 °C

Weight & dimensions

Processor package size: 37.5 x 37.5 mm

Processor special features

Intel® OS Guard: Yes

Intel® Boot Guard: Yes

Intel® Turbo Boost Technology 2.0 frequency: 4.3 GHz

Intel® Thermal Velocity Boost: No

Intel® Transactional Synchronization Extensions: No

Intel® vPro™ Platform Eligibility: No

Intel Software Guard Extensions (Intel SGX): Yes

Intel Turbo Boost Max Technology 3.0: No

Intel 64: Yes

Intel® Identity Protection Technology (Intel® IPT): Yes

Intel Trusted Execution Technology: No

Intel Stable Image Platform Program (SIPP): No

Intel® Optane™ Memory Ready: Yes

Intel® Secure Key: Yes

Intel® Quick Sync Video Technology: Yes

Intel® Hyper Threading Technology (Intel® HT Technology): Yes

Enhanced Intel SpeedStep Technology: Yes

Intel Virtualization Technology for Directed I/O (VT-d): Yes

Intel Virtualization Technology (VT-x): Yes

Intel® InTru™ 3D Technology: Yes

Intel® Turbo Boost Technology: 2.0

Intel® Clear Video HD Technology (Intel® CVT HD): Yes

Intel® AES New Instructions (Intel® AES-NI): Yes

Intel VT-x with Extended Page Tables (EPT): Yes

Intel Clear Video Technology: Yes

Other features

Maximum internal memory: 128 GB

Logistics data

Harmonized System (HS) code: 85423119
