Switch Ruijie Reyee RG-NIS2100-4GT2SFP-HP

Περιγραφή

Design

Product colour: Black, Stainless steel

Reset button: Yes

Rack mounting: Yes

Housing material: Metal

Number of fans: 0 fan(s)

Wall mountable: Yes

DIN rail mounting: Yes

Power

Power saving mode (EEE): Yes

Power supply location: Internal

Power source: DC/PoE

DC voltage range: 46 - 57 V

Number of power supply units: 1

Power supply included: Yes

Surge protection voltage: 6 kV

Power consumption (max): 192 W

Surge protection: Yes

Security

DHCP features: DHCP client, DHCP snooping

Operational conditions

Operating relative humidity (H-H): 10 - 90%

Storage relative humidity (H-H): 5 - 95%

Storage temperature (T-T): -40 - 85 °C

Heat dissipation: 1067.04 BTU/h

Operating altitude: -500 - 5000 m

Operating temperature (T-T): -40 - 75 °C

Management features

Web-based management: Yes

Cloud-managed: Yes

Quality of Service (QoS) support: Yes

Switch type: Managed

System event log: Yes

Switch layer: L2

Weight & dimensions

Weight: 770 g

Width: 50 mm

Height: 30 mm

Depth: 155 mm

Network

Networking standards: IEEE 802.1Q

Ethernet Ring Protection Switching (ERPS): Yes

VLAN support: Yes

Port mirroring: Yes

Broadcast storm control: Yes

Number of VLANs: 16

10G support: No

Performance

Mean time between failures (MTBF): 200000 h

Packaging data

Package weight: 1.08 kg

Packaging content

Manual: Yes

Rack mount kit: Yes

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC)

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 4

Installed SFP modules quantity: 2

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Gigabit Ethernet (copper) ports quantity: 4

Other features

Warranty period: 5 year(s)

Data transmission

MAC address table: 8000 entries

Switching capacity: 12 Gbit/s

Forwarding rate: 8.9 Mpps

Jumbo frames: 10000

Jumbo frames support: Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE) type supported: PoE+, PoE++ (4PPoE)

Power over Ethernet 4PPoE (PoE++) ports quantity: 1

Power over Ethernet (PoE) ports quantity: 4

Power over Ethernet (PoE): Yes

Power over Ethernet plus (PoE+) ports quantity: 4

Total Power over Ethernet (PoE) budget: 180 W
