ASUS Pro WS TRX50-SAGE WIFI AMD TRX50 Socket sTR5 SSI CEB

Περιγραφή

Processor

Processor socket: Socket sTR5

Processor manufacturer: AMD

Compatible processor series: AMD Ryzen™ Threadripper™

Features

Motherboard chipset: AMD TRX50

Motherboard form factor: SSI CEB

Component for: Workstation

Windows operating systems supported: Windows 11, Windows 10 x64

Product colour: Black

Audio chip: Realtek ALC1220P

Motherboard chipset family: AMD

Memory

Memory slots type: DIMM

ECC: Yes

Supported memory types: DDR5 ECC RDIMM

Memory channels: Quad-channel

Number of memory slots: 4

Weight & dimensions

Width: 305 mm

Depth: 280 mm

Network

Wi-Fi: Yes

Top Wi-Fi standard: Wi-Fi 7 (802.11be)

Ethernet interface type: 10 Gigabit Ethernet, 2.5 Gigabit Ethernet

LAN controller: Intel I226-LM

Bluetooth version: 5.4

Ethernet LAN: Yes

Wi-Fi standards: Wi-Fi 7 (802.11be)

Bluetooth: Yes

Internal I/O

ATX Power connector (24-pin): Yes

Front panel audio connector: Yes

USB 2.0 connectors: 2

Number of SATA III connectors: 4

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1

Number of COM connectors: 1

Chassis intrusion connector: Yes

Number of chassis fan connectors: 4

EPS power connector (8-pin): Yes

CPU fan connector: Yes

TPM connector: Yes

USB 3.2 Gen 2x2 connectors: 1

12V power connector: Yes

Integrated SAS ports: 1

BIOS

BIOS type: UEFI AMI

Clear CMOS button: Yes

BIOS memory size: 256 Mbit

Packaging data

Package weight: 4.85 kg

Package width: 320 mm

Package height: 100 mm

Package depth: 380 mm

Packaging content

Cables included: PCIe, SATA

Storage controllers

RAID levels: 1, 10, 0, 5

RAID support: Yes

Number of HDDs supported: 4

Number of storage drives supported: 7

Supported storage drive interfaces: M.2, SATA III

Supported storage drive types: HDD & SSD

Rear panel I/O ports

USB connector type: USB Type-A, USB Type-C

USB 2.0 ports quantity: 2

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 6

Ethernet LAN (RJ-45) ports: 2

Microphone in: Yes

S/PDIF out port: Yes

WiFi-AP antenna jack: 1

USB 3.2 Gen 2x2 Type-C ports quantity: 1

Expansion slots

Number of M.2 (M) slots: 3

PCI Express x16 (Gen 4.x) slots: 2

PCI Express x16 (Gen 5.x) slots: 3

Other features

Weight: 2.53 kg
