Asrock TRX50 WS motherboard

Περιγραφή

Processor

Compatible processor series: AMD Ryzen™ 7000 Series

Processor socket: Socket sTR5

Supported processor sockets: Socket sTR5

Processor manufacturer: AMD

Graphics

On-board graphics card: No

Features

Motherboard chipset family: AMD

Component for: PC

Motherboard chipset: AMD TRX50

Motherboard form factor: EATX

Memory

Supported memory module capacities: 32GB, 64GB, 24GB, 16GB, 48GB, 96GB

Memory slots type: DIMM

Supported memory types: DDR5-SDRAM

Memory channels: Quad-channel

ECC: Yes

Maximum internal memory: 1 TB

Number of memory slots: 4

Operational conditions

Operating temperature (T-T): -40 - 70 °C

Storage temperature (T-T): 10 - 35 °C

Weight & dimensions

Depth: 277 mm

Width: 305 mm

Network

Ethernet LAN: Yes

Wake-on-LAN ready: Yes

Internal I/O

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

TPM connector: Yes

Number of COM connectors: 1

Number of SATA connectors: 4

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1

ATX Power connector (24-pin): Yes

USB 2.0 connectors: 2

Number of chassis fan connectors: 3

BIOS

Clear CMOS button: Yes

BIOS type: UEFI AMI

Storage controllers

Supported storage drive interfaces: Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4)

Rear panel I/O ports

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4

Number of microphone inputs: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

Ethernet LAN (RJ-45) ports: 2

Line-out: Yes

Number of USB 3.2 Gen 2x2 (3.1 Gen 2x2) Type-C ports : 1

SPDIF optical output: Y

Number of antenna connectors: 2

Expansion slots

Number of M.2 (M) slots: 2

PCI Express x16 (Gen 5.x) slots: 3

PCI Express x16 (Gen 4.x) slots: 2
