Biostar H510MHP 2.0 motherboard Intel H510 LGA 1200 (Socket H5) micro ATX

Περιγραφή

Processor

Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®

Processor socket: LGA 1200 (Socket H5)

Processor manufacturer: Intel

Graphics

HDCP: Yes

DirectX version: 12.0

Features

Motherboard chipset: Intel H510

Windows operating systems supported: Windows 10 x64, Windows 11 x64

Audio chip: Realtek ALC897

Audio output channels: 7.1 channels

Motherboard form factor: micro ATX

Motherboard chipset family: Intel

Memory

Supported memory module capacities: 32GB, 4GB, 8GB, 16GB

Memory slots type: DIMM

Supported memory types: DDR4-SDRAM

Maximum internal memory: 64 GB

Number of memory slots: 2

Supported memory clock speeds: 2400, 3200 MHz, 2666, 1866, 2933, 2133

Weight & dimensions

Width: 185 mm

Depth: 226 mm

Network

Ethernet LAN: Yes

Wi-Fi: No

Ethernet interface type: Gigabit Ethernet

LAN controller: Intel® I219-V

Internal I/O

CPU fan connector: Yes

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1

Number of SATA III connectors: 4

Front panel audio connector: Yes

Number of COM connectors: 1

Front panel connector: Yes

ATX Power connector (24-pin): Yes

EPS power connector (8-pin): Yes

USB 2.0 connectors: 1

BIOS

Clear CMOS jumper: Yes

BIOS type: UEFI

Packaging content

User guide: Yes

Drivers included: Yes

Cables included: SATA

Storage controllers

Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III

Rear panel I/O ports

HDMI ports quantity: 1

Ethernet LAN (RJ-45) ports: 1

USB 2.0 ports quantity: 4

PS/2 ports quantity: 2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

Headphone outputs: 1

VGA (D-Sub) ports quantity: 1

Expansion slots

Number of M.2 (M) slots: 1

PCI Express x1 (Gen 3.x) slots: 2

PCI Express x16 (Gen 3.x) slots: 1
