ASUS PRIME B660-PLUS D4 Intel B660 LGA 1700 ATX

Περιγραφή

Processor

Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®

Supported processor sockets: LGA 1700

Processor manufacturer: Intel

Processor socket: LGA 1700

Features

Windows operating systems supported: Windows 10 x64, Windows 11 x64

Power source type: ATX

Motherboard form factor: ATX

Audio output channels: 7.1 channels

Motherboard chipset: Intel B660

Motherboard chipset family: Intel

Memory

Memory slots type: DIMM

Number of memory slots: 4

Supported memory types: DDR4-SDRAM

Memory channels: Dual-channel

Supported memory clock speeds: 4000, 4800, 3000, 3400, 3866, 3333, 4600, 2933, 3600, 2133, 3466, 2666, 4266, 3733, 4400, 5000, 2400, 2800, 5066

Maximum internal memory: 128 GB

ECC сompatibility: Non-ECC

Unbuffered memory: Yes

Weight & dimensions

Depth: 244 mm

Width: 305 mm

Height: 53 mm

Network

Ethernet LAN: Yes

Wi-Fi: No

Ethernet interface type: 2.5 Gigabit Ethernet

Internal I/O

Chassis intrusion connector: Yes

Number of COM connectors: 1

TPM connector: Yes

RGB LED pin header: Yes

EPS power connector (8-pin): Yes

Front panel connector: Yes

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2

ATX Power connector (24-pin): Yes

Number of chassis fan connectors: 3

USB 2.0 connectors: 2

S/PDIF out connector: Yes

Number of SATA III connectors: 4

Thunderbolt headers: 1

Front panel audio connector: Yes

CPU fan connector: Yes

BIOS

Clear CMOS jumper: Yes

BIOS type: UEFI AMI

Packaging content

Cables included: SATA

Storage controllers

Number of HDDs supported: 4

Number of storage drives supported: 7

Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III

RAID support: Yes

RAID levels: 5, 1, 0, 10

Supported storage drive types: HDD & SSD

Rear panel I/O ports

HDMI ports quantity: 1

VGA (D-Sub) ports quantity: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1

HDMI version: 2.1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

Headphone outputs: 3

DisplayPort version: 1.4

Ethernet LAN (RJ-45) ports: 1

USB connector type: USB Type-A, USB Type-C

DisplayPorts quantity: 1

USB 2.0 ports quantity: 2

Expansion slots

PCI Express x16 (Gen 4.x) slots: 1

Number of M.2 (M) slots: 3

PCI Express x16 (Gen 3.x) slots: 1

PCI Express x1 (Gen 3.x) slots: 2

Other features

Weight: 891 g

Logistics data

Harmonized System (HS) code: 84733020

Safety warning

Warnings: Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
