FLIR C3-X​ thermal imaging camera Black 1800 mAh Vanadium Oxide Uncooled Focal Plane Arrays Built-in display 128 x 96 pixels LCD 640 x 480 pixels

Περιγραφή

Technical details

Sustainability certificates: RoHS

Design

Built-in display: Yes

Display diagonal: 8.89 cm (3.5")

Product colour: Black

Operating temperature (T-T): -10 - 50 °C

Storage temperature (T-T): -40 - 70 °C

International Protection (IP) code: IP54

Display type: LCD

Housing material: Aluminium

Display resolution: 640 x 480 pixels

Package type: Box

Weight & dimensions

Package width: 160 mm

Height: 24 mm

Package weight: 517 g

Package height: 94 mm

Depth: 84 mm

Width: 138 mm

Package depth: 117 mm

Weight: 190 g

Performance

IFOV (spatial resolution): 7.9 mRad

Wi-Fi: Yes

Compatible memory cards: Not supported

Horizontal field of view: 53.6°

Sensor resolution (thermal module): 128 x 96 pixels

Thermal sensitivity (NETD): 70 mK

Infrared spectral band: 8 - 14 µm

Temperature measurement range: -20 - 300 °C

GPS (satellite): No

Standard palettes: Grayscale, High Contrast, Hot metal, Ironbow

Sensor type (thermal module): Vanadium Oxide Uncooled Focal Plane Arrays

Thermal frame rate: 8.7 Hz

Packaging content

Manual: Yes

Cables included: USB Type-C

Batteries included: Yes

Wrist strap included: Yes

Certificates

Waste Electrical and Electronic Equipment (WEEE) compliance: Yes

Ports & interfaces

USB port: Yes

Battery

Input current: 1 A

Rechargeable battery: Yes

Battery life (max): 4 h

Battery capacity: 1800 mAh

Battery recharge time: 2 h

Input voltage: 3.7 V

Battery technology: Lithium-Ion (Li-Ion)

Lens system

Fixed focus: Yes
